7 Ton Single Drum Vibratory Rollers
Categories: Single Drum Mechanical Driven Vibratory Road Roller
Operating Weight: 7000 kgs
Drum Width: 1700 mm
Driving Type: mechanical driven
Standard: CE
7ton, 1700mm drum width, mechanical rear wheel driven, hydrualic
vibration, articulated steering; pneumatic smooth rear tires; xinchai
498 diesel engine; front & rear scraper and sprinkler; standard
cabin.
|
Operating mass |
7000 kg |
|
Static linear load |
215 N/cm |
|
Vibration amplitude |
0.4 mm |
|
Vibration frequency |
43 Hz |
|
Centrifugal force |
70 kN |
|
Travel speed (I/II/III) |
2.2/4.7/15 km/h |
|
Grade ability |
25 % |
|
Turning radius |
6000 mm |
|
Overall dimension |
5030 X 1880 X 2570 mm |
|
Vibration round width |
1700 mm |
|
Wheelbase |
2750 mm |
|
Ground clearance |
305 mm |
|
Diesel model |
498BG |
|
Rated power |
42 kw |
|
Rated speed |
2200 r/min |
